Tubing Retrievable Subsurface Safety Valve
Retaj oil field tubing-retrievable ‚ surface controlled ‚ subsurface safety valves are value engineered to provide long-lasting ‚safe‚ and reliable operation.
Wire line Retrievable Subsurface Safety Valve
Retaj oil field safety valves are wire line retrievable‚ poppet-type subsurface-controlled subsurface safety valves‚ available in 3‚000 psi (20.6 Mpa) and 10‚000 psi (68.9 Mpa) operating pressure variants.
Packer Production
Production Packers are the most widely used most versatile high performance Retrievable & permanent production packers available. They are frequently used as a permanent squeeze or testing packer or as a permanent or temporary bridge plug‚ and Retrievable Production Packer is a multi-use‚ dependable set down packer used for production ‚stimulation and testing operations.
Sliding Sleeve
The Sliding Sleeve is a tubing run‚ mechanically shifted sleeve‚ used in production tubing to establish communication between the tubing and the casing. The sleeve facilitates production of several zones through one tubing string‚and allows zone –specific tasks to be performed ‚including testing and stimulation. The Sliding Sleeve opens and closes using conventional wireline shifting equipment.
Entry Guide
Wireline Entry Guide is designed to be run on the bottom of the tubing string. It will aid wireline tools that have passed out the bottom of the tubing to re-entry without hanging up. Specify tubing size and thread.
Flow Coupling
Flow Couplings are used in the tubing staring of a flowing well ‚in conjunction with Nipples ‚Safety Valves ‚or Sliding Sleeves ‚to protect the tubing from abrasive action caused by turbulent flow through restricted areas. As a general rule ‚a Flow Coupling should always be used when the flow control device is installed on a permanent basically on a safety valve
Latch Assembly System
Latch assembly positions the seal in the polished bore of the packer at the bottom of the available stroke. With a slight amount of set-down weight‚ the anchor latch will snap into the top thread of the packer mandrel or polished bore receptacle . This feature allows an upward pull to be applied to the tubing string to positively confirm proper location and operation.
Mechanical Receivable Test Packer
Retrievable Strom Packer surreal soused in Production‚ stimulation‚ perforating‚ gravel packing and testing application. The hydraulic hold down is below the pressure equalization valve. The tool features approve three element packing system and a hydraulically controlled balance piston designed to keep they-pass closed when set.
No Go Nipple
Profile Nipple is a TOP No Go Nipple that provides for the location of various wire line flow control devices in the production string.
Lock Mandrel
The Retaj oil field Lock Mandrel has upward and downward facing locking dogs to prevent both upward and downward movement. A No-Go profile is machined into the lock mandrel itself.
