Hydraulic Nin-rotating Liner hanger
Liner hanger is a hydraulic-set liner hanger that does not compromise on performance. Unlike competitors’ liner hangers ‚the Retaj oil field has six slips per cone(Similar competitors ’products feature three slips per cone.) The Retaj oil field is a ideal hanger for liners that do not jave to be reamed or drilled down.
Hydraulic Rotating Liner Hanger
Hydraulic rotating liner is Retaj oil field top-of-the-range liner hanger. It features protected slips‚a heavy-duty bearing‚ and tandem cones. It has the highest hanging capacity of all Retaj oil field liner hangers and can be deployed in even the most challenging wells. The hanger can be rotated after the slips is set and is typically run in conjunction with rotating running tool‚which allows vigorous rotation of the liner to bottom.
Machanical Non-rotating Liner Hanger
Liner Hangers is one of the most reliable and efficient Mechanical Set Liner Hangers‚ as it is comprised of the hanger body or mandrel‚ one or more sets of cone pads ‚ slips and a cage assembly to carry the slips. The cage contains slot and drag springs to control the movement of the slips into contact with the cones. A lug on the hanger body controls the cage slot. A gauge ring protects the slips when running the hanger into the wellbore. Non-Rotating Mechanical Set Liner Hangers are set through manipulation the work string: quarter right hand tum aligns the cones and the slips, after which slack offsets the slips into the casing wall.
Liner Hangers is one of the most reliable and efficient Mechanical Set Liner Hangers‚ as it is comprised of the hanger body or mandrel‚ one or more sets of cone pads ‚ slips and a cage assembly to carry the slips.
Top Set Packer
The Retaj oil field liner-top packer is a premium packer that is suited for most application. The packer features hold-down slips and an element that is rated to 7,500 psi (48.3 MPa) at 300˚F (149˚C) in most sizes.
